Triple Decker Structure





Triple Decker Structure

Maximize vertical space with KENTEN’s multi-level tent structures — the premium solution for urban events, festivals, and high-capacity temporary facilities.

INQUIRY ONLINE

Features
Specifications
Why Choose Us
Applications
Cases
FAQ

Features

Robust Aluminum Alloy Frame

Built with extruded 6061/T6 aluminum, our frame offers exceptional strength and a lifespan of 15~20 years.

Fully Customized

Widths range from 10 m to 30 m, extendable in 5 m bays. Three floors, each 3.3–4 m tall, allow up to 12 m in total eave height. Floor heights and spans are tailored to your needs.

Flexible Interior Options

Choose from internal or external staircases, balconies, mezzanine levels, glass or PVC walls, and flooring systems including cassette or wood.

Efficient Space Utilization

Expand vertically instead of outward — ideal for venues with limited ground area.

Weather-Resistant & Durable

High-quality PVC fabric is waterproof, UV-resistant, and flame-retardant, ensuring long-lasting performance in all climates.

Versatile Layouts

Perfect for VIP lounges, exhibitions, viewing decks, and multi-purpose levels with endless design possibilities.

Specifications

Item	Specification
Clear Span Width	A Frame Design / Flat Roof Design:10m/20 m/25 m/30 m.
Side Height (First floor)	4 m
Side Height (Second floor)	4 m
Eave Height	12 m
Ridge Height	A Frame Design:13.625m. Flat Frame Design:12.615 m.
Bay Spacing	5 m
Wind Loading	115 MPH
Floor Loading Capacity	200 kg/m²~500 kg/m²

Item	Specification
Roof Pitch	A Frame Design:18° Flat Roof Design:7°
Main Profile	300 x 120 x 5 x 7 mm, 350 x 120 x 5 x 7 mm
Roof Options	Single-layer Roof Fabric, Double-layer Inflatable Roof Fabric
Roof Fixing	TR20 Tensioning Screw Rod
Eave Connection	Hot-dip Galvanized Twin Steel Plate
Framework Material	Hard Pressed Extruded Aluminium Alloy 6061/T6
Cover Material	PVC-coated Polyester Textile, Opaque, Water Proof, 850 g/m². Flame Retardant

Detailed Inquiries, Please Contact Sales Manager.

KENTEN Triple Decker Structure VS Regular Triple Decker Structure

	KENTEN Structures	Others
Aluminum	6061 T6 / 6082 T6	6063 T5 / 6005 T5
PVC Fire Retardant	B1,M2	B2
Wind Resistance	Up to 120 km/h	Up to 80 km/h
Lifespan	20 Years (Frame)	10 Years (Frame)

Why Choose KENTEN Triple Decker Structure?

Maximize Space

Three full levels of usable area without increasing your footprint — perfect for city venues, racetracks, or trade shows.

Prestige & Visual Impact

A towering, multi-level structure instantly elevates your event and brand image, offering a premium, building-like presence.

Functional Zones

Ground floor: Registration, dining, product showcases

Second floor: Meetings, lounges, hospitality spaces

Top floor: Executive suites, media booths, VIP experiences

Engineered for Reliability

Withstands strong wind and snow loads. PVC fabric is UV-resistant, waterproof, and fire-retardant.

Fast Installation & Reusable

Set up in days, not weeks. Modular, reusable, and relocatable for multiple events.

Cost-Effective Alternative

Get the function of a permanent building at a fraction of the cost.

Applications

High-end Exhibitions & Trade Shows

F1 and Motorsport Events

Major Sports Tournaments

VIP Hospitality & Media Centers at Concerts and Festivals

Video

Our Cases

Every solution put into practice is a precise match between scenario and need

Frequently Asked Questions About Triple Decker Structure

Q1: What is a Three-Story Tent?

A:A modular, clear-span structure with three functional floors — designed for premium events, exhibitions, sports hospitality, and temporary architecture.

Q2: What size options are available?

A:Widths: 10–30 m; Length: unlimited (extendable in 5 m bays); Floor height: 3.3–4 m each.

What materials are used?

Frame: 6061-T6 aluminum alloy

Roof & walls: PVC-coated polyester, UV-resistant, waterproof, fire-retardant (B1/NFPA 701)

Optional: Glass walls

Q3: What customization options are offered?

A:Glass or PVC sidewalls

Internal/external staircases

Balconies & terraces

Flooring systems (cassette, wood, carpet)

HVAC, lighting, branding panels, signage

Q4:Can it be relocated or reused?

A:Yes. Fully modular and demountable — ideal for traveling events or seasonal use.

Q5:Can it be used permanently?

A:Yes, with proper anchoring and fit-outs, it can function as a semi-permanent structure.

Q6:Is it suitable for extreme weather?

A:Yes. Engineered for wind speeds up to 100 km/h and heavy snow loads.

Q7:Do you provide design support?

A:Absolutely. We offer 3D layouts, engineering drawings, and full interior planning.
