Pagoda Tent





The KENTEN Pagoda Tent is a premium temporary outdoor structure recognized for its distinctive high-peak, pyramid-style roof and modern elegance. Designed for quick installation and long-lasting performance, it’s a favorite choice for private parties, hotel hospitality, exhibitions, brand activities, and upscale outdoor events.

INQUIRY ONLINE

Features
Specifications
Why Choose Us
Applications
Cases
FAQ

Features

Quick & Easy Assembly

With its lightweight 6061-T6 aluminum alloy frame and modular design, the Pagoda Tent can be installed in just hours—requiring only a small setup crew.

Spacious, Unobstructed Interior

The clear-span structure has no internal support poles, providing a completely open space for flexible layouts. Standard sizes span up to 10 meters, offering generous room for guests and activities.

Stylish, Modern Appearance

The iconic peak roof delivers a sleek, contemporary look that elevates any event setting while making a strong visual impact.

Strong & Durable Structure

Made from high-strength 6061-T6 aluminum alloy with a hot-dip galvanized steel insert, the frame ensures excellent stability and long-term reliability.

Premium, All-Weather Canopy

Covered with UV-resistant, waterproof, flame-retardant PVC-coated polyester fabric (DIN 4102 B1/M2, BS 5438/7837, NFPA701 compliant), the canopy resists heat absorption and keeps interiors cooler and more comfortable.

High Value & Low Maintenance

Lightweight, corrosion-resistant, and mildew-proof, the Pagoda Tent offers excellent cost performance with minimal upkeep.

Specifications

Width	Side Height	Ridge Height	Bay Spacing	Longest Componet
3.00 m	2.50 m	4.40 m	3.00 m	3.00 m
4.00 m		5.00 m	4.00 m	4.00 m
5.00 m		5.30 m	5.00 m	5.00 m
6.00 m		5.60 m	6.00 m	6.00 m
8.00 m		6.40 m	8.00 m	8.00 m
10.00 m		6.80 m	10.00 m	10.00 m

Standard side height is 4 m. Side heights 2.5 m to 3.5 m are available upon request.

Frame	4 Channels, Hard Pressed Extruded Aluminium Alloy 6061/T6.
Cover Material	1) White color, PVC coated 2) Waterproof, Anti-UV,Flame Retardant According to DIN 4201,B1/M2,NFPA701 3) Weight of roof cover:800-950 g/square meter(opaque PVC) 4) Weight of side wall cover:650 G/square meter(translucent PVC)
Optional Accessories	PVC Window Side walls Lining & Curtain Glass Door Units Glass Wall System ABS Solid Wall System Transparent PC Solid Wall Transparent PVC Cover and Side wall Floor System, Lighting Weight Plate Anchor.
Wind Resistance	80~100 km/h
Fixing Solution	Ground Anchor, Expandable Bolt, Weight Plate, etc.
Service Life	More than 15 years
Applicable temperature range	-30 degree Celsius ~ +70 degree Celsius
Ground Situation	Grassland,Earth Land,Asphalt,Cement Ground,Marble,etc
Connectors	Hot-dip Galvanized Steel Insert.
Additional Services	1) Provide video guidance for installation. 2) Provide engineering calculations for tent structure’s wind, snow, and seismic resistance. 3) Technical professionals provide on-site installation guidance services.

For More Information, Please Contact Sales Manager.

KENTEN Pagoda Tent VS Regular Pagoda Tent

	KENTEN Structures	Others
Aluminum	6061 T6 / 6082 T6	6063 T5 / 6005 T5
PVC Fire Retardant	B1,M2	B2
Wind Resistance	Up to 100 km/h	Up to 80 km/h
Snow Load Capacity	Medium to High	Medium

Why Choose KENTEN Pagoda Tents?

Full Customization

Tailor size, shape, wall type, flooring, and color schemes to fit your brand or event theme.

Premium Quality

High-strength aluminum alloy frame and advanced PVC canopy ensure durability and safety in all weather conditions.

Simple Setup & Transport

Modular construction makes it easy to assemble, disassemble, and store compactly.

Applications

Private Celebrations & Outdoor Parties

Media and Press Events

Exhibition Booths & Product Showcases

Brand Promotions

Video

Our Cases

Every solution put into practice is a precise match between scenario and need

2022 Formula 1 Miami Grand Prix

19th Asian Games – Hangzhou 2023

2008 Beijing Olympic Games

2022 Beijing Winter Olympic Games

2022 Formula 1 Montreal Grand Prix

2025 Doha Photography Exhibition

2025 Formula 1 Canadian Grand Prix

American Customer Customized Atrium Tent For Wedding

Customized Atrium Wedding Tent

Customized Warehouse Project For Chilean Customers

Customized Warehouse Project for Chilean Client

Toyota New-Car Launch Event

Frequently Asked Questions About Pagoda Tent

Q1: Is it easy to install a pagoda tent?

A:Yes, small to medium-sized pagoda tents are relatively easy to set up and can usually be completed in a few hours without the help of professionals. The installation process for large tents (10 x 10 m and above) is relatively complex, but can still be completed quickly without mechanical hoisting, requiring only a small engineering team.

Q2: Can pagoda tents function normally in strong winds?

A:Our pagoda tents can still function normally in strong winds. We use high-quality materials and an aluminum alloy structural frame. The maximum wind load capacity is 100 km/h.

Q3: What aspects of the pagoda tent can I customize?

A:We offer pagoda tents in various sizes. Accessories include walls, doors, floors, etc. Our PVC fabric can be customized in different colors and patterns to meet your needs.
