| Span Width | Length | Eave Height | Ridge Height | Bay Spacing |
| 20.00 m | Unlimited | 4 M/5 M | 10.00 m | 5.00 m |
| 25.00 m | 12.50 m | |||
| 30.00 m | 15.00 m | |||
| 35.00 m | 17.50 m | |||
| 40.00 m | 20.00 m |
| Aluminum Alloy Frame Material | |
| Structure Frame Material | 4 Channels, Hard Pressed Extruded Aluminium Alloy 6061/T6 |
| Main Profile Size | 20 M:200 x 120 x 4 x 4.5 MM |
| 25 M:250 x 120 x 4 x 6 MM | |
| 30 M:300 x 120 x 5 x 7 MM | |
| 35 M:300 x 120 x 5 x 7 MM | |
| 40 M:300 x 120 x 5 x 7 MM, 350 x 120 x 5 x 7 MM | |
| Eave Connection/Fixing | Hot-dip galvanized twin plate; Ground stakes or weight anchoring upon request |
Detailed Inquiries, Please Contact Sales Manager.

Every solution put into practice is a precise match between scenario and need

A: Yes, it is built to withstand wind up to 120 km/h and can be reinforced for snow load.
A: Absolutely. You can add full-skin branding, interior/exterior lighting, or even use it as a projection dome for immersive effects.
A: Yes, the dome structure allows for open, column-free space, ideal for seating, screens, or installations.
A: Yes, the frame and fabric are both built for long-term, repeat use with proper care and storage.
