Dome Tent





With its striking curved architecture, robust engineering, and versatile customization options, KENTEN Dome Tent is the ideal choice for upscale outdoor events, luxury hotels, exhibitions, and brand showcases. Whether used as a single centerpiece or combined into a larger complex, the Dome Tent delivers both visual impact and reliable performance.

INQUIRY ONLINE

Features
Specifications
Why Choose Us
Applications
Cases
FAQ

Features

Distinctive Aesthetics

The unique semi-spherical or oval design creates a bold, modern look. Its smooth, sweeping curves add symmetry and visual appeal, making it a true focal point for any event or venue.

Built for All-Weather Reliability

Frame: Heavy-duty Q235 steel for exceptional strength and stability.

Cover: Premium PVC tarpaulin (850g/m²) that’s waterproof, UV-resistant, flame-retardant, and highly durable.

Withstands strong winds and snow loads, ensuring year-round usability.

Fast & Efficient Installation

Factory-prefabricated components allow for quick on-site assembly—medium-sized dome tents can be set up by just a few people in a short time.

Modular & Expandable

The modular design makes it easy to connect multiple domes, expand interior space, or add custom platform systems for extended functionality.

Fully Customization

Choose your ideal size, fabric color, patterns, and accessories—from glass walls and doors to lighting, flooring, and climate control—to create a space that reflects your brand and style.

Multi-Purpose Applications

With its spacious interior and premium finish, the Dome Tent is perfect for high-end events, VIP lounges, exhibitions, product launches, private parties, and more.

Specifications

Diameter	Ridge Height	Structural Layers	Pipe Diameter	Base Plate	Area
10 M	5 M	6	Ø32 * 1.5 mm	36	78.5 m²
15 M	7.5 M	6	Ø32 * 1.5 mm	36	176.625 m²
20 M	10 M	7	Ø42 * 2.0 mm	42	314 m²
25 M	12.5 M	9	Ø42 * 2.0 mm	54	490.625 m²
30 M	15 M	11	Ø48 * 2.5 mm	54	706.5 m²
35 M	17.5 M	11	Ø48 * 2.5 mm	66	961.625 m²
40 M	20 M	12	Ø60 * 3.0 mm	72	1256 m²

Frame	Q235 Steel Frame
Cover Material	1) White color, PVC coated 2) Waterproof, anti-UV, flame retardant according to DIN 4201, B1/M2, NFPA701 3) 800-950 g/square meter (opaque PVC) 4) 650 G/square meter (translucent PVC)
Optional Accessories	PVC Window Side Walls Glass Window Lining & Curtain Glass Door Units Cover and Side Walls Floor System, Lighting Air Conditioner
Wind Resistance	80~100 km/h
Fixing Solution	Ground Anchor, Expandable Bolt, Weight Plate, etc.
Service Life	More than 15 years
Applicable temperature range	-30 degree Celsius ~ +70 degree Celsius
Ground Situation	Grassland, Earth Land, Asphalt, Cement Ground, Marble, etc
Connectors	Hot-dip Galvanized Steel Insert.
Additional Services	1) Provide video guidance for installation. 2) Provide engineering calculations for tent structure’s wind, snow, and seismic resistance. 3) Technical professionals provide on-site installation guidance services.
